LX-884 Automatic four-station magnetic ring machine

Produc features:
 The novel appearance streamline design, simple and reliable, compact and reasonable structure, to adapt to the working environment characteristics of strong, high accuracy;
 This series of winding machine using the latest version of ESM research and development of high performance machine software, touch screen real-time programming, user-friendly operation interface in teaching, English optional dialogue, easy and simple operation; password storage function, prevent unauthorized persons to modify the program, high efficiency, convenient maintenance, less faults;

Description

Product series:
The model series type: 4 axis (LX-884)。
Produc features:
 The novel appearance streamline design, simple and reliable, compact and reasonable structure, to adapt to the working environment characteristics of strong, high accuracy;
 This series of winding machine using the latest version of ESM research and development of high performance machine software, touch screen real-time programming, user-friendly operation interface in teaching, English optional dialogue, easy and simple operation; password storage function, prevent unauthorized persons to modify the program, high efficiency, convenient maintenance, less faults;
The winding products：
Magnetic ring inductance ring power suplly transformer

Type	LX-884
Spindle numder	4
Spindle pitch	500mm
Maximum core diameter	80mm
Core height	10～40mm
Product inner diameter	30mm
Motor power	X:400 Y:400 Z:400 Spindle：1000（stundard）
Winding motor speed	0.8-1.5秒/圈(stundard)
Cotntroller Controller	ESM CNC multi-axis motion controller
Programming method	Touch screen
Storage method	Direct storage + USB
Traverse moving range	X：100mm Y：100mm Z：120mm	X：100mm Y：100mm Z：120mm
Accuracy	±0.1°
Adapt to line length	100-1800mm
Wire range	0.5—2.6mm
Air pressure	4-6kgf/c㎡
Power voltage	AC220V/50HZ(AC110V/60HZ)
Total power	4KW
Machine weight	500KG
Machine size	1150W1000L1600Hmm
Package dimensions	1450W1200L1650Hmm
